Sensitivity for full rated power |
1.4 Volts RMS or 0.775 Volts |
|
Frequency Response 20 Hz to 20 KHz |
1dB at any power level |
|
Signal to Noise ratio 20 Hz to 20 KHz |
More than
105 dB |
|
Total Harmonic Distortion (THD) |
0.1% |
|
Intermodulation Distortion (IMD) |
0.05% |
|
Damping Factor |
1000 From 20 Hz to 400 Hz. |
|
Load Impedance |
Safe with all types of loads |
|
Output power stereo mode at 8 ohm
(stereo) |
1200 + 1200 Watts RMS
(both channels driven) |
|
Output power stereo mode at 4 ohm
(stereo) |
2400 + 2400 Watts RMS
(both channels driven) |
|
Output power stereo mode at 2.66 ohm
(stereo) |
3200 + 3200 Watts RMS
(both channels driven) |
|
Output power stereo mode at 2 ohm
(stereo) |
2600 + 2600 Watts RMS
(MODE LZ) |
|
Output power bridged mode at 16 ohm (mono) |
2400 Watts RMS |
|
Output power bridged mode at 8 ohm
(mono) |
4800 Watts RMS |
|
Output power bridged mode at 4 ohm
(mono) |
5200 Watts RMS
(MODE LZ) |
|
Overload and short-circuit protection system |
Current limited controlled by ACC at 52A per CH. |
|
Overheat protection system |
Cut-off at internal 85 Deg. Resume at 55
Deg. |
|
Power Supply protection |
Soft start - Against all severe voltage fluctuations |
|
AC
Input Voltage without affecting max. Output Power |
180 V - 250 Volts AC.
(when loading 4 ohms) |
|
AC
Input Voltage at moderate power operation |
140 V - 250 Volts AC.
(when loading 4 ohms) |
|
Dimensions W x D x H |
480 x 460 x 66 mm (1.5U. 19" Rack mount ) |
|
Weight |
12.3 Kg. |
